Home PA6-GF

PA6-GF

Selected:
Size: 1.75MM | Weight: 1 KG | Color: Black
Sale price AED 330.00
Size: 1.75MM
Weight: 1 KG
Color: Black
SKU: N08-K0-1.75-1000-SPL

Product Features

  • Superior Strength and Stiffness
  • Toughness & Vibration Resistance
  • Exceptional Thermal Resistance
  • Comes with High Temperature Reusable Spool
  • Diameter: 1.75mm +/- 0.03mm


Cautions for Use

  • 0.2 mm Nozzle Not Compatible
  • Stainless Steel Nozzle Not Recommended
  • Dry before Use
  • Enclosure Printers Required
  • AMS & AMS lite NOT Compatible
Add to Wishlist Add to Compare

Notify me when available

Register to receive a notification when this item comes back in stock.

Ask a question
Share

Estimate delivery times: 1-2 days

Return within 2 days of purchase.

Guarantee Safe Checkout

Visa
Mastercard
American Express
Diners Club
Apple Pay
Google Pay
Tabby

Bambu PA6-GF - Glass Fiber Reinforced Nylon

Bambu PA6-GF, also known as Nylon 6 with Glass Fiber, stands at the forefront of high-performance engineering plastics. Engineered to deliver exceptional strength, durability, dimensional stability. The PA6-GF is also more cost effective when compared to other top tier engineering filaments.

Built to Last
Bambu PA6-GF is exceptionally strong and durable due to reinforced glass fibers, making it the perfect choice for prints that need to withstand heavy use and resist bending or breaking.
* Note: The printed part achieves better toughness after exposure to moisture.
Dimensional Stability
PA6-GF boasts unparalleled dimensional stability thanks to its glass fiber reinforcement, minimizing warping in comparison to standard PA filaments. Print with precise dimensions, even in the most intricate geometries.

Impact & Vibration Resistance

Exceptional Thermal Properties
PA6-GF boasts a high heat deflection temperature and superior dimensional stability, enabling it to retain its mechanical properties even under elevated temperatures. This makes it ideal for demanding industrial and automotive applications.
Chemical Resistance
PA6-GF offers excellent resistance to chemicals, oils, and many kinds of solvents, ensuring long-term performance in challenging environments.
Smooth Surface and More Colors
Bambu PA6-GF filaments are compatible with the Bambu AMS system, ready to print in multi-color. The special surface texture also blurs the layer lines, providing a smooth surface quality.
RFID for Intelligent Printing
All printing parameters are embedded in RFID, which can be read through our AMS (Automatic Material System).
Load and print! No more tedious setting steps.

Technical Specifications

Drying Settings before Printing 80 °C, 8 - 12 h
Printing and Keeping Container's Humidity < 20% RH (Sealed, with Desiccant)
Nozzle Temperature 260 - 290 °C
Bed Temperature (with Glue) 80 - 100 °C
Printing Speed < 130 mm/s
Density 1.14 g/cm³
Vicat Softening Temperature 210 °C
Heat Deflection Temperature 182 °C
Melting Temperature 219 °C
Melt Index 9.0 ± 0.8 g/10 min
Tensile Strength 75 ± 6 MPa
Breaking Elongation Rate 3.9 ± 0.8 %
Bending Modulus 3670 ± 140 MPa
Bending Strength 120 ± 6 MPa
Impact Strength 27.2 ± 2.2 kJ/m²
